CAT 5 Wiring Tips

App image

download for windows phone

App Description

Did you know you can make your own Cat 5 Ethernet network cables and save a lot of money in the process? Cat 5 Wiring Tips shows how to wire for “straight through” and “crossover” cable configurations using the Telecommunications Industry Association TIA-568-B standard. Also, there is a reference on how to use 8 connector Ethernet wire for6 pin/ 6 connector phone connectors.

Scan tag to download

Version History

Version 1.4

  • Tap each wiring diagram for a text description of the diagram (for those with color blindness)
  • Added new “more info” pivot page with a video how to of cable creation
  • New “about” page

Version 1.3

Recompiled for Mango.

Version 1.2

New screenshot and direct links

Version 1.1

New marketplace images

Version 1.0

Initial Release
